Choosing displays for medical devices: part 2

PART 2.

Professional framework for the selection process

The first part of the article discussed the parameters and features to consider when designing a medical display. Go to Part 1.

In this summarizing part, you will find a practical guide to selecting the ideal display for your healthcare application, based on years of experience addressing the needs and solving the problems of Riverdi’s medical customers.

Topics covered:

• Key factors to consider when selecting a display for medical devices.
• Step-by-step guide to choosing the optimal display.
• The importance of longevity and customization in medical display solutions.
• A case study highlighting common challenges and solutions in display integration.

The importance of R&D decisions

Choosing the right display for a medical device is a critical decision that can significantly affect the device’s performance, usability and safety. Whether designing a new device or upgrading an existing one, it is essential to carefully consider factors such as size, resolution, touch capability and longevity.

This article provides a step-by-step guide to help engineers and designers select an optimal display and explains why industrial-grade technology is recommended for the specific requirements of medical applications. Additionally, a real-world case study is included to highlight potential issues in display integration and solutions to avoid them.

Step-by-step guide to choosing an optimal medical display

When selecting a display for a healthcare device, follow these steps:

1. Determine the required size and information displayed
   • Evaluate the amount of information that needs to be shown on the screen. Common sizes range from 2” to 12”, depending on the application.
2. Select the appropriate resolution
   • Estimate the required resolution—higher or lower—based on the detail level needed.
   • Multiple resolution options may be available for a given size; choose the one that best meets your needs.
   • Riverdi displays typically offer high resolution, ensuring clear representation of detailed information.
3. Determine brightness and touch capabilities
   • High brightness is crucial for medical applications, especially in varying lighting conditions. A minimum of 1000 cd/m² is recommended for optimal visibility.
   • Select an industrial-grade touchscreen that:
     – Operates with gloves or when liquids are present on the screen.
     – Includes an optional fluid detection feature that locks the screen until it is cleaned, preventing potentially life-threatening touch errors.
4. Consider longevity and availability
   • Medical devices generally require at least 10 years of availability on the market.  This is essential not only for ensuring long-term supply, but also justifying the time-consuming and costly design process, which typically takes from 2-5 years.
   • Therefore, check product longevity early in the design process to ensure availability throughout the device’s lifecycle.

Most standard Riverdi displays provide an excellent foundation for ensuring extended longevity, with guaranteed availability for over 5 years and some components accessible for up to 15 years. This makes them a reliable choice for long-term medical applications, where it is crucial to guarantee that the selected display remains available for years to come.

Case study: challenges in display integration

In one recent case, a U.S.-based customer mass-producing a virus testing device faced significant challenges due to inadequate display selection. The device featured a polycarbonate cover with an air gap between the cover and the touch sensor. Such a combination of air and plastic created an equivalent thickness of 7-8 mm of glass due to electrical permittivity. This exceeded the capabilities of the consumer-grade controller chosen by their previous display manufacturer. As a result, the device experienced touch sensitivity issues, leading the customer to maximize the controller’s sensitivity to make the touch function at all. However, this adjustment made the controller unable to handle background noise, leading to false touch events—a critical issue in the medical field due to potential life-threatening consequences.

Riverdi’s solution involved redesigning the sensor and controller using industrial-grade components capable of handling the 7-8 mm stack while maintaining the existing mechanical structure. ​​This approach eliminated the need for costly retooling and effectively resolved the touch sensitivity problems.



Summary of key factors in medical display selection

Carefully consider the following to ensure maximum effectiveness for your project.

Final pro tips

For engineers and designers working on a medical device project, it is crucial to address display selection early in the development process. Begin by reviewing the key factors above, then contact Riverdi’s experts for customization services adjusted to your specific application needs. Making informed decisions from the start ensures compliance with rigorous medical certifications, avoids costly redesigns, and guarantees reliable device performance in critical environments.

Explore Riverdi’s product series below, offering over 300 standard industrial-grade models. Testing samples early with no MOQ and consulting with our team will help fine-tune your design and optimize it for long-term success.
